ETD KiloWatt Concept
ETD Portfolio
A collection of enclosure designs and thermal analyses.
Specifications
Housing Dimensions (LxWxH): 12.92" x 11.14" x 6.43"
Housing Weight: 21.27 lbs (9.65 Kg)
Max Heat Load: 1000 W
Modularized 250 Watt Unit
Specifications
Housing Dimensions (LxWxH): 8.10" x 5.50" x 5.35"
Housing Weight: 5.51 lbs (2.50 Kg)
Max Heat Load: 250 W
Max Heat Load: 200 W
200 Watt Unit
Specifications
Housing Dimensions (LxWxH): 7.73" x 7.00" x 4.00"
Housing Weight: 4.37 lbs (1.98 Kg)
Max Heat Load: 200 W
Max Heat Load: 200 W
140 Watt Unit
Specifications
Housing Dimensions (LxWxH): 6.90" x 5.00" x 3.08"
Housing Weight: 3.68 lbs (1.67 Kg)
Max Heat Load: 140 W
Max Heat Load: 200 W
Light Weight Unit #1
Light Weight Unit #2
Specifications
Housing Dimensions (LxWxH):
6.90" x 5.00" x 3.08"
Housing Weight: 0.65 lbs
(0.29 Kg)
Max Heat Load: 25 W
Specifications
Housing Dimensions (LxWxH):
7.35" x 2.57" x 1.42"
Housing Weight: 0.77 lbs
(0.35 Kg)
Max Heat Load: 45 W
Media
Gallery
Outline Drawing
Conduction Dependent Unit #1
Conduction Dependent Unit #2
Specifications
Housing Dimensions (LxWxH):
4.20" x 9.15" x 1.40"
Housing Weight: 1.92 lbs
(0.87 Kg)
Max Heat Load: N/A
Media
Gallery
Outline Drawing
Specifications
Housing Dimensions (LxWxH):
3.92" x 3.72" x 1.98"
Housing Weight: 0.66 lbs
(0.30 Kg)
Max Heat Load: N/A
200 Watt Free Convection Unit
Light Weight Unit #3
Specifications
Housing Dimensions (LxWxH):
10.50" x 9.15" x 5.53"
Housing Weight: 10.60 lbs
(4.81 Kg)
Max Heat Load: 200 W
Media
Gallery
Outline Drawing
Specifications
Housing Dimensions (LxWxH):
6.30" x 4.80" x 2.00"
Housing Weight: 0.77 lbs
(0.35 Kg) (Magnesium Alloy)
Max Heat Load: 65 W
Media
Gallery
Outline Drawing
Want to see more?
Head over to the Contact page or click the Chat Box. Leave as much info as you are comfortable with. Just be sure to mention "would like to see full portfolio" to receive access to ETD's extended portfolio.
Want to see more?
Head over to the Contact page or click the Chat Box. Leave as much info as you are comfortable with. Just be sure to mention "would like to see full portfolio" to receive access to ETD's extended portfolio.
2U Rack Unit
120 Watt Unit
Specifications
Rack Dimensions (LxWxH):
16.93" x 16.93" x 3.46" (2U)
Rack Weight: N/A
Max Heat Load: N/A
Specifications
Housing Dimensions (LxWxH):
5.63" x 6.13" x 1.79"
Housing Weight: 2.33 lbs
(1.06 Kg)
Max Heat Load: 120 W
